INDUS ELECTRO CONTROLS PRODUCT COVERS THE FOLLOWING
» Motor Control Centres (Fixed & Draw Output type)
» Distribution Boards
» Capacitor Panels
» Power Control Centers
» Synchronising and AMF Panels
» PLC, Drive Panels
» Relay Control Panels
» Busducts
Our panels have been successfully tested for the following by leading Electrical testing authority of India, M/s. CPRI
» 65 KA short circuit LT Panel
» 50 KA Short Circuit for LT Panel
» 26 KA Short Circuit for HT Panel
» 28 KV Insulation Level for HT Panel
» IP 54
» IP 55
» 50KA Short Circuit for Bus ducts
Frames of panels are made from formed profiles and bolted together. Precision tools are used to achieve a higher accuracy.
Liberally spaced busbars for rating upto 4000A contonuous and 50kA RMS fault current for 1 Sec.
Non hygroscopic, fire retardant FRP barrier and SMC insulators for busbars to ensure increased safety.
Specious cable chambers to facilitate easier cable terminations.
All types of panels have been supplied to leading Multinationals, SAIL, Power Plants. Chemical Plants Software companies etc., through leading consultants.
